Wisper Wayfarer H9 Hub-Drive Crossbar

The Wayfarer H9 mid drive, crossbar is the perfect all-rounder. In City spec it is a comfortable commuter or day to day workhorse but underneath the city exterior beats the heart of a true thoroughbred, the Wayfarer super hi torque motor developing 50Nm at the rear wheel, almost the same as 100Nm at the pedals. Strip off the comfort products and change the tyres and you have the perfect off-roader for a day in the hills and forests.

Motor

Wisper Hi Torque Rear Hub Drive 43.2V 250W Nominal

Lithium Battery

In frame, secure removable. Chargeable in or out of frame
On/off button with LED charge status light.
Standard 450Wh
Long range 700Wh

Assisted range

Total load, terrain, road surface, tyre pressures, speed, power setting, wind conditions and motor power all have a huge bearing on an eBike’s bikes range. With this in mind, you may expect to achieve the following AVERAGE ranges. Due to the number of outside factors affecting all electric bikes, our published ranges are estimates only, based on our experience and are not guaranteed.
450Wh battery 20 – 40 miles (30 – 60km)
700Wh battery 30 – 60 miles (50 – 100km)

Controls

Wisper Back lit LCD display with remote controls
Thumb throttle to 4mph (6km/h) walk along
Thumb throttle to 15.5mph (25km/h) assist booster

Bicycle weight

450Wh: 26kg
700Wh: 28kg

Frame

Hand welded, 6061 Alloy T4 and T6 tempered

Forks

Suntour XCM 30 100mm travel

Frame size

18” 46cm

Frame Colour

Pillar Box Red or Sky Blue 6 coats

Seat post

31.6mm 350mm with 100mm safety line

Saddle

Wisper Comfort, eBike with seat handle

Kick stand

Black anodised alloy

Gears

Shimano Altus 8 speed with Rapid Fire shifter

Chain

KMC X8 rust resist 8 speed

Chain drive

Prowheel 48t

Freewheel

13 to 34

Brakes

Wisper Apex Hydraulic disc brakes, 2.5 finger F180mm R160mm

Wheels

Alloy black anodised double wall 27.5” x 1.24″ (31.4mm)

Tyres

Kenda 27.5” 2.2 high puncture resistance with reflector

MTB/Adventure Bike Tyre Upgrade (optional extra)
Schwalbe Smart Sam Perf, DD, RaceGuard, Folding 27.5” x 2.25” First class all-rounder with extra safe Double Defence puncture protection 3mm GreenGuard layer, SnakeSkin sidewall. ECE-R75 approved for great riding fun on your E-Mountain or E-Adventure Bike. Wayfarer rims can take tyres of up to 2.25″ wide without fouling forks or frame. Tyres larger than 2.25″ wide can only be used without mudguards.

Mudguards

Black Anodised Aluminium 2.6″

Lighting

Front: Spaningo XE 6V powered from bike battery
Rear: Spaningo XE 6V powered from bike battery

Rear Rack

Wisper integrated custom, 17kg limit

Front Rack (optional extra)

Wisper integrated custom, 10kg limit

Max Weight Load Inc. Luggage
21st 135kg
